One of the most requested line additions in AutoMeter history, this Digital Stepper Motor Exhaust Pressure Gauge has been engineered to the highest standards of accuracy and durability. Precisely monitor your exhaust backpressure to maximize power and efficiency and ensure turbo longevity. Also ideal for cam tuning, includes a highly advanced 1/8” NPT Pressure Transducer, install kit and wiring harness for ease of installation. Data Logging is also possible thanks to an analog .5 - 4.5v output. An optional particulate filter is also available for enhanced sensor lifespan.
- Traditional incandescent lighting illuminates around the perimeter of the dial
- Includes data acquisition grade solid-state pressure transducer, providing unmatched accuracy and durability even in the harshest environments
- AutoMeter’s race proven digital stepper motor electric instruments provide unmatched accuracy while keeping hazardous gases outside of the vehicle
- The accuracy of digital stepper motor gauges is further increased by utilizing a self calibration sequence during power up
- Gauge kit includes 1/8” NPT stainless steel pressure transducer, copper tubing kit, wiring harness, mounting hardware, and detailed instructions for installation
- 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
- Recommended Particle Trap Kit (#5375) available separately for increased lifespan of the pressure transducer and ease of gauge hardware maintenance
Attributes:
- Brand Name: AutoMeter
- GTIN: 00046074043925
- Bezel Color: Brushed Aluminum
- Bezel Style: Super Bezel
- Cross Sell: 5375, 3284, 3285, 3286, 3287, 3288
- Cup/Hole Size - Metric - MM: 52.4mm
- Cup/Hole Size - Standard - IN: 2-1/16"
- Dial Color: Silver
- Gauge Type: Exhaust Pressure
- Includes Adapter/Fitting: 1/8" NPT Male to 1/8" compression fitting, 1/8" NPT Female to 1/8" compression fitting, 1/8" NPT to 1/4" NPT bushing
- Includes Bulb & Socket: 3220
- Includes Light Covers: Red 3214 & Green 3215
- Includes Mounting Hardware: 2230
- Includes Sensor Unit: 2229
- Includes Tubing: 6 ft. Copper Tube
- Includes Wire Harness: 5227
- Lens Style: Flat, Clear
- Lighting Color: White Incandescent
- Lighting Type: Incandescent
- Movement: Electric, Digital Stepper Motor
- Outer Bezel Diameter: 2-1/4"
- Outer Bezel Diameter - Standard: 2-1/16"
- Pointer Color: Fluorescent Red
- Range: 0-60 PSI
- Related Item: 2164, BEX-1500, EP-800, 0424XL, 0449XL, 0447LXL
- Series: ULTRA-LITE
- Size - Metric - MM: 52.4mm
- Size - Standard - IN: 2-1/16"
- Upsell: 5375, 3284, 3285, 3286, 3287, 3288
Extended Information:
- Country of Origin: US
- Emissions : CARB Eligible
Packing Information:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 5.25 x 5.5 x 5.5 inches
- Weight: 1.4 POUNDS
