Equip your vehicle with the Kleinn onboard air system, engineered specifically for owners who demand professional-grade utility and precision vehicle-specific fitment. This premium heavy-duty kit provides a reliable high-volume air source directly on your chassis, allowing you to easily inflate massive thirty-nine inch tires at the end of a day of four wheeling, power air lockers, operate air tools, or tackle demanding off-road challenges. The heart of this high-performance system features a heavy-duty waterproof air compressor and air tank configuration. For ultimate protection during rugged trail use, the entire compressor and tank assembly is shielded by a rugged steel cage featuring an integrated skid plate. This system features a true 100 percent bolt-on installation using common hand tools, requiring absolutely no cutting, welding, or drilling, and everything needed arrives in one box for a professional setup. Designed with future expansion in mind, this versatile pneumatic foundation includes pre-installed mounting studs and dedicated air ports, allowing you to easily upgrade to a dual compressor system by adding the part number JK6450 kit. Built to endure the toughest environments, this complete package provides the ideal balance of discreet original equipment manufacturer style mounting and high-output performance that serious trail builds count on.
- Vehicle Specific Bolt-On Onboard Air System
- Model 1302 - Quick Connect Relocation for Inflation
- Direct Fit Mounting Brackets
- No Drilling or Modifications required – 100% Bolt-On Installation
- Complete Wiring Including, Horn Button, Tank Fittings, 1 Compressor Relay
- Model 6450RC – High Output 150 PSI (200 Max) Waterproof Air Compressor
- Model 6353RT 3 Gallon Air Tank with 9-1/4" NPT Ports, inner Cortec coating for anti corrosion.
- Compatible with 4-Door Jeep JLU and JKU only (Excludes 4 Cyl, Diesel, Hybrid, and JLU with OEM Bottom Skid Plate on drivers side)
- Use model JK6450 for Add On 2nd Compressor to make the kit a dual compressor set up for 50% faster Inflation and Recovery time
- Model INF-1 - Tire Inflation Kit
- 2018-2026 Jeep JL Unlimited / 2007-18 Jeep JK Unlimited - 4-Door Only. Excludes Models with OEM Bottom Skid Plate on Driver Side, 4 Cyl, Hybrid, 392 & Diesel Engines
Attributes:
- Brand Name: Kleinn Automotive Accessories
- GTIN: 00819147011738
- Feature 1: Compressor and Tank Protected with Steel Skid Plate
- Feature 2: Supports Air Bags, Air Lockers and Air Tools
- Model 1301: 160 PSI dash panel gauge with 12-volt ON/OFF switch
- Model 1302: Quick-connect Coupler relocation kit - place air source wherever you wish
- Model 6450RC: High Output Waterproof Air Compressor 200 PSI / 100% Duty Cycle
- Model INF-1: Luminescent Tire Inflator w/ clip-lock air chuck. 24' Hose, quick connect coupler and storage bag
- Mounting: Powder Coated Custom Mounting Brackets - Direct bolt-on, No drilling or cutting
- Mounting Location: Tank and Compressor: Mid Jeep Between Drive Shaft and Exhaust
- Upgrades Available: Add Bolt-On Dual Train Horns - Model JK-220 for JKU and Model JL-220 for JLU
Extended Information:
- Country of Origin: China
- Emissions : CARB Eligible
Packing Information:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 35 x 14 x 11 inches
- Weight: 63 POUNDS
