this results in numerous performance benefits including increased pressure tolerance and lower EGTs.We engineered this intercooler to provide substantial benefits on a stock truck, and also to support the power and boost levels of a highly modified truck.Offered in black or silver, the Mishimoto 6.0L Powerstroke intercooler is protected by our signature lifetime warranty.
- 3.35-in bar-and-plate core is 33-percent thicker than factory
- 32.5-percent increase in core volume
- End tanks strategically designed for optimal airflow
Attributes:
- Brand Name: Mishimoto
- GTIN: 00748666004900
- Core Color: Black
- Core Height: 21.54
- Core Length: 25.75
- Core Material: Aluminum
- Core Thickness: 0
- Grade Type: Performance
- Height: 25.2
- Inlet Fitting Gender: Male
- Inlet Outside Diameter: 3.25
- Inlet Tank Material: Aluminum
- Install Difficulty: 3
- Length: 38.5
- OptionLabel: Black
- Outlet Fitting Gender: Male
- Outlet Outside Diameter: 3
- SellingPoint01: Direct fit for the 2003-2007 Ford 6.0L Powerstroke
- SellingPoint02: 3.35-in bar-and-plate core is 33-percent thicker than factory
- SellingPoint03: 32.5-percent increase in core volume
- SellingPoint04: End tanks strategically designed for optimal airflow
- SellingPoint05: Air diverter in hot-side end tank reduces turbulence and evenly distributes airflow across core
- SellingPoint06: Reduces turbo stress and extends life
- SellingPoint07: Available in Sleek Silver and Stealth Black
- SellingPoint08: Provides improved airflow and lowers intake air temperatures
- SellingPoint09: Mishimoto Lifetime Warranty
- SellingPoint10: N/A
- SellingPoint11: N/A
- SellingPoint12: N/A
- SellingPoint13: N/A
- SellingPoint14: N/A
- SellingPoint15: N/A
- TechSpec Applications: 2003-2007 Ford F-250 w/ 6.0L Powerstroke--2003-2007 Ford F-350 w/ 6.0L Powerstroke--2003-2007 Ford F-450 w/ 6.0L Powerstroke--2003-2007 Ford F-550 w/ 6.0L Powerstroke--2003-2005 Ford Excursion w/ 6.0L Powerstroke
- TechSpec Centerline Radius: N/A
- TechSpec Chassis Codes: N/A
- TechSpec Core Height (in): 21.54
- TechSpec Core Length (in): 25.75
- TechSpec Core Thickness (in): N/A
- TechSpec Core Type: Bar-and-Plate
- TechSpec Engine Codes: N/A
- TechSpec Includes: (1) Mishimoto Intercooler--Mishimoto Lifetime Warranty
- TechSpec Inlet (in): 3.25
- TechSpec Installation Notes: N/A
- TechSpec Maximum Recommended Boost Pressure (PSI): N/A
- TechSpec Maximum Recommended Horsepower: N/A
- TechSpec Note: N/A
- TechSpec Outlet (in): 3
- TechSpec Overall Height (in): 25.2
- TechSpec Overall Length (in): 38.5
- TechSpec Overall Width (in): 7.5
- TechSpec Pipe Diameter: N/A
- TechSpec Pipe Length: N/A
- TechSpec Pipe Shape: N/A
- TechSpec Weight (lbs): N/A
- Type: Bar-and-Plate
- Universal Or Specific Fit: Specific
- Width: 7.5
Extended Information:
- Country of Origin: CN
- Emissions : EPA Eligible
Packing Information:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 41 x 11 x 28 inches
- Weight: 69 POUNDS
