The ProLink XXL provides winch owners with a means to replace the conventional winch hook with a safer and stronger screw pin shackle/D-ring. Originally designed for 24,000 lb. military winch applications, the ProLink XXL is now available to the general public. Like all models in the ProLink family, the XXL is engineered and made in the USA from 6000 series billet aluminum and is equipped with a 3/4? 6Al-4V titanium double shear pin. The base of the XXL is protected by a barbed, high durometer EPDM rubber guard. Working load limit of 24,000 pounds and an ultimate failure of over 63,000 pounds. The XXL is compatible with steel cables and synthetic ropes up to 1/2" in diameter. The XXL is compatible with common 3/4? and 7/8? shackles.
- Fits all steel cables and synthetic ropes up to 1/2" diameter
- Billet construction ? precision machined from 6061-T6 Aluminum round bar
- 5? tall and 4? in diameter
- EPDM rubber guard protects hawse and roller fairleads
- Engineered, tested, and made in USA ? patent pending
Attributes:
- GTIN: 00012748095057
- Brand Name: Factor 55
- Add-on: 00465
- Color: GREEN
- Finish: Powdercoat
- Material: 6061 Aluminum
Extended Information:
- Country of Origin: US
- Emissions : Emissions Compliance Exempt
- Life Cycle Status: Available To Order
Packing Information:
- Quantity of Each: 1
- Package UOM: EA
- Dimension: 4 x 6 x 4 inches
- Weight: 2.44 lb
