RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module 30 Inch

  • Sale
  • Regular price $1,449.99


The RIGID Adapt E-Series LED Light Bar features the same style and construction as RIGIDs legendary E-Series, from the high-strength aluminum heat sink to the unbreakable polycarbonate lens. On the inside, however, the Adapt E-Series contains cutting-edge technology. The Adapt E-Series takes off-road lighting performance to a whole new level with two layers of adaptive response to your vehicle and driving conditions.
  • Universal Fit, Fits All Existing E-Series Grilles and Mounts
  • Use In Adapt Mode Or All On
  • Limited Lifetime Warranty
  • Alloy Housing and Heatsink
  • Unbreakable Polycarbonate Lens
  • Pressure Equalizing Vent
  • Black Exposed Printed Circuit Board
  • Patented Optics
  • 50,000 Hr+ LED Lifespan
  • Off Road Use Only
  • Harness, Switch & Relay Included
  • 3 Optic Zones - Scene, Driving, Spot
  • Seamless Beam Transition
  • Slow Speed, Moderate Speed & High Speed Beam Patterns
  • 9-36 VDC
  • Two Layers of Adaptive Response
  • Active Power Management System - Power Capacity Sensing
  • Active View Technology - Internal GPS Module

Additional Attributes:

  • GTIN: 00849774033148
  • A = LUX at 10 Meters: 5364
  • Add-On: 11001, 11002, 11003, 11008, 46590, 1063, 1067, 1031, 30130, 30140, 30150
  • ASIN: No
  • B= Beam Distance with 1 LUX: 732
  • C= Beam Distance with .25 LUX: 7165
  • Field Horizontal (Measured in Degrees): 17
  • Field Vertical (Measured in Degrees): 16
  • Number of LEDs: 64
  • Peak Beam Intensity (cd): 536407
  • Product Family: Adapt
  • Product Fits What: Universal Fit
  • Product Weight: 8.78
  • Raw Lumens: 20944
  • Size: 30 in.
  • Watts: 170
  • What's In The Package: Stainless Steel Mounting Brackets, Hardware Kit, Wire Harness, Relay, Switch, Install Instructions
  • Zone 1 A: 50
  • Zone 1 Amp Draw: 6.3
  • Zone 1 B: 71.3
  • Zone 1 C: 142.6
  • Zone 1 Horizontal Field beam angle: 101.7
  • Zone 1 LED's count: 8
  • Zone 1 Peak CD: 5087
  • Zone 1 Raw Lm: 8641
  • Zone 1 Vertical Field beam angle: 97.2
  • Zone 1 Watts: 88
  • Zone 2 A: 1316.77
  • Zone 2 Amp Draw: 10.6
  • Zone 2 B: 362.9
  • Zone 2 C: 725.7
  • Zone 2 Horizontal Field beam angle: 49.2
  • Zone 2 LED's count: 28
  • Zone 2 Peak CD: 131677
  • Zone 2 Raw Lm: 19040
  • Zone 2 Vertical Field beam angle: 23
  • Zone 2 Watts: 149
  • Zone 3 A: 5364.07
  • Zone 3 Amp Draw: 12.1
  • Zone 3 B: 732.4
  • Zone 3 C: 1464.8
  • Zone 3 Horizontal Field beam angle: 17
  • Zone 3 LED's count: 28
  • Zone 3 Peak CD: 536407
  • Zone 3 Raw Lm: 20944
  • Zone 3 Vertical Field beam angle: 16.1
  • Zone 3 Watts: 170

Extened Information:

  • Emissions : Legal US
  • Life Cycle Status: Available To Order

Packaging:

  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 6 x 33.25 x 6 inches
