RIGID Adapt E-Series LED Light Bar With 3 Lighting Zones And GPS Module 40 Inch

  • Sale
  • Regular price $1,499.99


The RIGID Adapt E-Series LED Light Bar features the same style and construction as RIGIDs legendary E-Series, from the high-strength aluminum heat sink to the unbreakable polycarbonate lens. On the inside, however, the Adapt E-Series contains cutting-edge technology. The Adapt E-Series takes off-road lighting performance to a whole new level with two layers of adaptive response to your vehicle and driving conditions.
  • Use In Adapt Mode Or All On

Attributes:

  • GTIN: 00849774033162
  • Brand Name: RIGID Industries
  • A = LUX at 10 Meters: 7,425
  • Add-On: 11001, 11002, 11003, 11008, 46590, 1063, 1067, 1031, 30130, 30140, 30150
  • ASIN: No
  • B = Beam Distance with 1 LUX: 862
  • C = Beam Distance with .25 LUX: 1,723
  • Field Horizontal (Measured in Degrees): 17
  • Field Vertical (Measured in Degrees): 16
  • Number of LED's: 88
  • Peak Beam Intensity (cd): 742,460
  • Product Family: Adapt
  • Product Weight: 10.84
  • Raw Lumens: 29,920
  • Size: 40 in.
  • test series: Universal Fit
  • Watts: 231
  • What's In The Package: Stainless Steel Mounting Brackets, Hardware Kit, Wire Harness, Relay, Switch, Install Instructions
  • Zone 1 A: 52.85
  • Zone 1 Amp Draw: 6.3
  • Zone 1 B: 72.7
  • Zone 1 C: 145.4
  • Zone 1 Horizontal Field beam angle: 101.6
  • Zone 1 LED's count: 8
  • Zone 1 Peak CD: 5,285
  • Zone 1 Raw Lm: 8,641
  • Zone 1 Vertical Field beam angle: 96.4
  • Zone 1 Watts: 88
  • Zone 2 A: 1580.27
  • Zone 2 Amp Draw: 13.5
  • Zone 2 B: 397.5
  • Zone 2 C: 795.1
  • Zone 2 Horizontal Field beam angle: 50.6
  • Zone 2 LED's count: 40
  • Zone 2 Peak CD: 158,027
  • Zone 2 Raw Lm: 25,520
  • Zone 2 Vertical Field beam angle: 24.4
  • Zone 2 Watts: 189
  • Zone 3 A: 7424.6
  • Zone 3 Amp Draw: 16.5
  • Zone 3 B: 861.7
  • Zone 3 C: 1723.3
  • Zone 3 Horizontal Field beam angle: 17.5
  • Zone 3 LED's count: 40
  • Zone 3 Peak CD: 742,460
  • Zone 3 Raw Lm: 29,920
  • Zone 3 Vertical Field beam angle: 15.9
  • Zone 3 Watts: 231

Extended Information:

  • Country of Origin: MX
  • Emissions : Emissions Compliance Exempt
  • Life Cycle Status: Available To Order

Packing Information:

  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 6 x 43.25 x 6 inches
  • Weight: 15 lb
